Sega System C-2

HARDWARE DESCRIPTION | Main CPU : MC68000 @ 8.948862 Mhz | Sound chip : YM3438 @ 7.670453, SN76496 @ 3.579545 | Optional Sound Chip : UPD7759 @ 640 kHz | Video resoution : 320x224 | Hardware Features : Linescroll , column scroll and a raster interrupt with 2 bg planes, one with an option window, a sprite plane and several levels of priority | Board composition : One single Jamma board. | This hardware is based on the Genesis hardware, the main cpu, the sound cpu and the graphic processor are the same. The main cpu is just a bit faster (10Mhz instead of 8Mhz) and there is no Z80, the sound chip is driven by the main cpu. The dac is also replace by a uPD7759, the same as the System 16 hardware. ( | read this description for more infos | ) | Sometimes refered to as System 14. | System Pictures : | Main board | Emulators : | MAME | - | Charles MacDonald's System C Emulator | This hardware is based on | Sega Mega Drive/Genesis
