Fabricant inconnu

Mega-CD

| Home | Model 2. Click for large size. Technical Specs CPU : Motorola 68000 running at 12.5Mhz in parallel with the Megadrive�s C.P.U. Hardware Graphic Features : ASIC chip Biaxial Rotation Scaling Zoom RAM : 6 MBit Main 512 Kbit PCM 128 Kbit CD-ROM data cache memory 64 Kbit backup ROM : 1 MBit Bios. CD-ROM Drive : 1x speed 150 Kbytes a second data transfer rate CD Access Time : 1.4 seconds maximum 0.8 seconds minimum Audio : 8 channels PCM 3" and 5" music CDs CD+G discs Stereo Output Sampling : 32 KHz 16 bit D/A compatible 8x oversampling Frequency Response : 20 Hz to 20 KHz Dynamic Range : Greater than 90 db Channel Separation : Greater than 90 db Dimensions : 220(L) X 396(W) X 84(H) mm Price : 49, 800 � ($370) Japanese Release Release Date : December 12, 1991 - Japan System Notes/History The Mega CD did not improve the colours on the Megadrive although it did allow the Megadrive to display film footage F.M.V. Related Links Sega CD Scans Photo contributed by Aaron Mims .
